Absolute and gauge pressure measurement

Sản phẩm đơn giản
Dễ lựa chọn, cài đặt và vận hành

Công nghệ vượt trội

Đơn giản

FLEX là gì?

Sản phẩm tiêu chuẩn
Đáng tin cậy, mạnh mẽ và ít bảo trì

Công nghệ vượt trội

Đơn giản

FLEX là gì?

Sản phẩm cao cấp
Chức năng cao và tiện lợi

Công nghệ vượt trội

Đơn giản

FLEX là gì?

Sản phẩm chuyên dụng
Dành cho các ứng dụng đòi hỏi cao

Công nghệ vượt trội

Đơn giản

Có thể thay đổi

FLEX là gì?

Lựa chọn FLEX	Công nghệ vượt trội	Đơn giản
F L E X Lựa chọn Fundamental Đáp ứng nhu cầu đo lường cơ bản	Công nghệ vượt trội	Đơn giản
F L E X Lựa chọn Lean Xử lý dễ dàng các quy trình cốt lõi	Công nghệ vượt trội	Đơn giản
F L E X Lựa chọn Extended Tối ưu hóa quy trình bằng công nghệ tiên tiến	Công nghệ vượt trội	Đơn giản
F L E X Lựa chọn Xpert Làm chủ các ứng dụng khó khăn nhất	Công nghệ vượt trội	Đơn giản Có thể thay đổi

Tìm hiểu thêm về các lựa chọn FLEX

So sánh

Cerabar PMP71B - pressure transmitter

Smart pressure transmitter - its health can be verified without process interruption

Accuracy Standard:
up to 0.05 %
Platinum:
up to 0.025 %

Process temperature Standard:
-40°C…+125°C
(-40°F…+257°F)
Diaphragm seal:
-40°C...+400°C
(-40°F...+752°F)

Pressure measuring range 400 mbar...700 bar
(1.5 psi...10,500 psi)

Main wetted parts 316L, AlloyC,
Tantal, Monel,
PTFE, Gold

Material process membrane 316L, AlloyC,
Tantal, Monel,
PTFE,
Gold

Measuring cell 400 mbar...700 bar
(6 psi...10,500 psi)

So sánh

Absolute and gauge pressure Cerabar PMC21

Cost-effective pressure transducer with ceramic sensor for measurement in gases or liquids

Accuracy 0.3 %

Process temperature -25 °C…+100 °C
(-13 °F....+185 °F)

Pressure measuring range +100 mbar…+40 bar
(+1.5 psi...+600 psi)

Measuring cell +100 mbar…+40 bar
(+1.5 psi...+600 psi)

Cerabar PMC51 - Absolute and gauge pressure

So sánh

Absolute and gauge pressure Cerabar PMC51

Digital pressure transmitter with oil-free ceramic sensor for measurement in gases or liquids

Accuracy Standard 0.1%
Platinum 0.075%

Process temperature -20°C...130°C
(-4°F...266°F)

Pressure measuring range 100 mbar...40 bar
(1.5psi...600psi)

Process pressure / max. overpressure limit 60 bar (900 psi)

Main wetted parts Ceraphire
Sealing
Alloy C276
316L

Max. measurement distance 400 m (1312 ft) H2O

Material process membrane Ceramic

Measuring cell 100 mbar...40 bar
(1.5 psi...600 psi)
relative/ absolute

Cerabar PMC71 - Absolute and gauge pressure

So sánh

Absolute and gauge pressure Cerabar PMC71

Digital pressure transmitter with oil-free ceramic sensor for measurement in gases or liquids

Accuracy Standard: 0.05%
Platinum: up to 0.025%

Process temperature -40°C...150°C
(-40°F...302°F)

Pressure measuring range 100mbar...40bar
(1.5psi...600psi)

Process pressure / max. overpressure limit 60bar (900psi)

Main wetted parts Ceraphire ceramic
Alloy C
316L
Monel
PVDF

Max. measurement distance 400m (1312ft) H2O

Material process membrane Ceramic

Measuring cell 100 mbar...40 bar
(1.5 psi...600 psi)
relative/ absolute

So sánh

Absolute and gauge pressure Cerabar PMP21

Cost-effective pressure transducer with metal sensor for measurement in gases or liquids

Accuracy 0.3%

Process temperature -40…+100°C
(-40…+212°F)

Pressure measuring range 400 mbar…+400 bar
(6...+6000psi)

Measuring cell +400 mbar…+400 bar
(+6 psi...+6000 psi)

So sánh

Absolute and gauge pressure Cerabar PMP23

Cost-effective pressure transducer with fully welded design for the food & beverage industry

Accuracy 0.3%

Process temperature -10…+100°C
(+14…+212°F)
135°C for 1h
(275°F for 1h)

Pressure measuring range 400 mbar…+40 bar
(6...+600psi)

Measuring cell +400 mbar…+40 bar
(+6 psi...+600 psi)

New

So sánh

Cerabar PMP43 – hygienic pressure transmitter

Particularly compact, highly reliable and the perfect fit for demanding hygienic applications

Accuracy Standard 0.1%
Platinum 0.075%

Process temperature -40°C...+130°C (-40°F...+266°F)
-20°C...+200°C (-4°F...+392°F)

Pressure measuring range 400 mbar...100 bar
(6 psi...1450 psi)

Material process membrane 316L

Measuring cell 400 mbar...100 bar
(6 psi...1450 psi)

Cerabar PMP51 - Absolute and gauge pressure

So sánh

Absolute and gauge pressure Cerabar PMP51

Digital pressure transmitter with welded metal sensor for measurement in gases, steam or liquids

Accuracy Standard 0.1%
Platinum 0.075%

Process temperature -40°C...130°C
(-40°F...266°F)

Pressure measuring range 1 bar...400 bar
(15 psi...6000 psi)

Process pressure / max. overpressure limit 600 bar (9000 psi)

Main wetted parts 316L

Max. measurement distance 4000 m (13.123 ft) H2O

Material process membrane 316L, AlloyC,
Rhodium>Gold

Measuring cell 400mbar...400bar
(5.8 psi...6000psi)
relative/ absolute

So sánh

Cerabar PMP51B - pressure transmitter

Smart pressure transmitter with metal membrane for highly accurate measurement of liquids and gases

Accuracy Standard:
up to 0.075 %
Platinum
up to 0.055 %

Process temperature Standard:
-40°C…+125°C
(-40°F…+257°F)
Diaphragm seal:
-40°C...+400°C
(-40°F...+752°F)

Pressure measuring range 400 mbar... 400 bar
(6psi...6,000psi)

Main wetted parts 316L, AlloyC,
Tantal, Monel,
PTFE

Material process membrane 316L, AlloyC,
Tantal, Monel,
PTFE

Measuring cell 400 mbar...400 bar
(6psi...6,000psi)

Cerabar PMP55 - Absolute and gauge pressure

So sánh

Absolute and gauge pressure Cerabar PMP55

Digital pressure transmitter with fully welded diaphragm seal for measurement in gases or liquids

Accuracy Standard 0.15%
Platinum 0.075%

Process temperature -70°C…400°C
(-94°F…752°F)

Pressure measuring range 1 bar...400 bar
(15 psi...6000 psi)

Process pressure / max. overpressure limit 600 bar (9000 psi)

Main wetted parts 316L
AlloyC
Montel
Tantal
Rhodium

Max. measurement distance 4000m (13.123ft) H2O

Material process membrane 316L, AlloyC,
Tantal, PTFE,
Rhodium>Gold

Measuring cell 400 mbar...400 bar
(5.8 psi...6000 psi)
relative/ absolute

Our product finder helps you to search for suitable measuring devices, software or system components via product characteristics. Applicator leads you through an individual product selection via application parameters.

Go to product finder Go to Applicator

About absolute and gauge pressure measurement

Absolute and gauge pressure continuous measurement or pressure switches provide the safe measurement of liquids and gases in various applications. Cerabar sensors and Ceraphant switches monitor reliably the level in food applications. The devices have various hygienic approvals. Also in the process industry with SIL and explosion protection certificates there is reliable measurement guaranteed. Check out the broad range of Cerabar and Ceraphant devices and click on the button below.

Absolute and gauge pressure measurement with ceramic or silicon cell or diaphragm seal offer the perfect fit for various applications in the process and hygienic industries. With the right sensor technology and fit for purpose devices Endress+Hauser offers pressure transducers with quick setup or even just plug & play which allows simple commissioning, reduces costs and saves time - be it a pressure switch or a pressure transmitter.

Measuring Principle Pressure
